Discontinued
Extech MN47
12 Function Compact MultiMeter + NCV
The compact, manual ranging MN47 digital mini multimeter is equipped with the extensive capabilities for both active tradesman and hobbyist alike. In addition to its electronic and electrical testing functions, the MN47 adds value with a built in, non-contact voltage detector. You won't have to search for a voltage pen in order to safely check for voltage prior to attaching the multimeter's test leads. A bright red LED alerts you to the presence of voltage. Complete with test leads, bead wire Type K probe, 9 V battery, and a carrying case.
仕様
| 一般仕様 | |
|---|---|
| AC電圧 | 600V |
| AC電圧の最大解像度 | 0.1V |
| AC電流 | 10A |
| AC電流の最大解像度 | 0.1µA |
| DC電圧 | 600V |
| DC電圧の最大解像度 | 0.1mV |
| DC電流 | 10A |
| DC電流の最大解像度 | 0.1µA |
| ダイオード試験 | Yes |
| 周波数 | 10MHz |
| 周波数の最大分解能 | 0.001Hz |
| 導通 | Yes |
| 抵抗 | 40MΩ |
| 抵抗の最大解像度 | 0.1Ω |
| 温度（タイプK）の最大分解能 | 1400 °F (760 °C) |
| 負荷サイクル | 0.1 to 99.9% |
| 電気容量 | 100µF |
| 静電容量最大解像度 | 1pF |
| 非接触電圧（NCV）検出器 | 100 to 600VAC |
| 追加の詳細 | |
|---|---|
| ディスプレイ | 4000-count segment LCD |
| 保証 | 2 years |
| 出力 | 1 × 9V battery |
| 安全性カテゴリー | CATIII - 600V |
| 寸法 | 5.9 × 2.75 × 1.8" (150 × 70 × 48mm) |
| 認証 | CE |
| 重量 | 9oz (255g) |
