Discontinued

Extech MN47

12 Function Compact MultiMeter + NCV

The compact, manual ranging MN47 digital mini multimeter is equipped with the extensive capabilities for both active tradesman and hobbyist alike. In addition to its electronic and electrical testing functions, the MN47 adds value with a built in, non-contact voltage detector. You won't have to search for a voltage pen in order to safely check for voltage prior to attaching the multimeter's test leads. A bright red LED alerts you to the presence of voltage. Complete with test leads, bead wire Type K probe, 9 V battery, and a carrying case.

规格

一般参数
二极管测试 Yes
交流电压 600V
交流电压最大分辨率 0.1V
交流电流 10A
交流电流最大分辨率 0.1µA
占空比 0.1 to 99.9%
导通性 Yes
温度(K 型)最大分辨率 1400 °F (760 °C)
电容 100µF
电容最大分辨率 1pF
电阻 40MΩ
电阻最大分辨率 0.1Ω
直流电压 600V
直流电压最大分辨率 0.1mV
直流电流 10A
直流电流最大分辨率 0.1µA
非接触式试电笔 (NCV) 100 to 600VAC
频率 10MHz
频率最大分辨率 0.001Hz
其他详情
保修 2 years
安全等级 CATIII - 600V
尺寸 5.9 × 2.75 × 1.8" (150 × 70 × 48mm)
显示屏 4000-count segment LCD
电源 1 × 9V battery
认证 CE
重量 9oz (255g)
